Starter | 2 Pin 10mm HD IP20

$2.85 NZD
Approx $1.77 USD
IP Rating
ADD TO CART ADD TO CART

Starter | 10mm HD LED Strip IP20

Designed for use with iFlex HD and UHD LED strip lights, the starter clip proves a fast, easy and reliable way to connect strip lights to power supplies.  The connectors require no special tools and can be connected in seconds.

Cart

View Cart View Cart Check Out Check Out

Specifications

Strip Light Protection Level IP20
Wire Cross Section 0.34~0.75 mm²
Workable Wire Gauge 22 ~18 AWG
Workable Wire OD 2.1mm
Pin QTY 2
Pin Pitch 7.6mm
Way of Contact Insulation Piercing Contact
Working Voltage 3V - 24V
Rated Current 5Amp
Housing Color (cap/base) Clear/Black
Min.LED Strip Thickness >0.2mm
Housing Material Polycarbonate
Pin Material Phosphor coated copper
Flame Retardant Level UL94v-0

Features

Starter | 10mm HD LED Strip IP20

Designed for use with iFlex HD and UHD LED strip lights, the starter clip proves a fast, easy and reliable way to connect strip lights to power supplies.  The connectors require no special tools and can be connected in seconds.

SLC ConnectX SEN10XB-2G Enquire About This Product Enquire About This Product



  • Description
  • Key Specification
  • Accessories
  • Downloads

Starter | 10mm HD LED Strip IP20

Designed for use with iFlex HD and UHD LED strip lights, the starter clip proves a fast, easy and reliable way to connect strip lights to power supplies.  The connectors require no special tools and can be connected in seconds.
